产品特点： |
||
| 1.扫描速度极快,测量点分布规则； | |||
| 2.精度高,单次测量范围大； | |||
| 3.大景深； |
|
参 数 Parameter |
内 容 Content |
描 述 Description |
||
|
微显示芯片 Micro-display panel |
0.3" DMD TRP |
Single panel |
||
|
分辨率 Resolution |
1280 × 720 | 720p HD | ||
|
画幅比例 Aspect ratio |
16 : 9 | |||
|
光通量 Luminous (lm) |
55 lm @ 30W | ANSI | ||
|
光源 Light Source |
RGBB-LED | |||
|
寿命(小时) Lifetime(hrs) |
20000 | |||
|
投射比 Throw ratio |
4.6 | |||
|
对比度 Contrast |
1000 : 1 | Full on / Full off | ||
|
均匀度 Uniformity |
> 85% | |||
|
TV 畸变 TV Distortion |
< 0.5% | |||
|
调焦方式 Focusing |
Manual | |||
|
偏轴率 Offset |
0% | |||
|
色温(K) Color Temperature(K) |
> 6500 | |||
|
投射尺寸(英寸) Projection size (inch) |
1.6" ~ 20" | 0.17 ~ 2m | ||
|
尺寸(mm) Dimension(mm) |
76 × 74 × 26 | w/o heatsink | ||
| F / # | 5 | 6 | 7 | 8 |
|
DOF @Projection Distance 300mm |
±5mm | ±6mm | ±7mm | ±8mm |
